The WSF40N06 is the highest performance trench N-Ch MOSFET with extreme high cell density, which provides excellent RDSON and gate charge for most of the synchronous buck converter applications. The WSF40N06 meets the RoHS and Green Product requirement, with 100% EAS guaranteed and full function reliability approved.
| Symbol | Parameter | Rating | Units |
|---|---|---|---|
| VDS | Drain-Source Voltage | 60 | V |
| VGS | Gate-Source Voltage | ±20 | V |
| ID@TC=25℃ | Continuous Drain Current, VGS @ 10V1 | 50 | A |
| ID@TC=100℃ | Continuous Drain Current, VGS @ 10V1 | 32 | A |
| ID@TA=25℃ | Continuous Drain Current, VGS @ 10V1 | 10 | A |
| ID@TA=70℃ | Continuous Drain Current, VGS @ 10V1 | 8 | A |
| IDM | Pulsed Drain Current2 | 200 | A |
| EAS | Single Pulse Avalanche Energy3 | 42 | mJ |
| IAS | Avalanche Current | 28 | A |
| PD@TC=25℃ | Total Power Dissipation4 | 53 | W |
| PD@TA=25℃ | Total Power Dissipation4 | 3.5 | W |
| TSTG | Storage Temperature Range | -55 to 150 | ℃ |
| TJ | Operating Junction Temperature Range | -55 to 150 | ℃ |
