Built-in 64KB FLASH, supports finished C port online upgrade software.
Comply with WPCV1.2 version QI protocol standard.
Supports a variety of 5-15W launch applications.
Supports simultaneous charging of 3 devices including mobile phone, earphones and watch.
Support FOD (Foreign Object Detection) function.
Support NTC temperature protection, built-in multi-channel ADC, reliable over-voltage, over-temperature and output over-current protection.
| Parameters | Sign | Minimum Value | Typical Value | Maximum Value |
|---|---|---|---|---|
| voltage | VDD | 0.3V | 5V | 5.8V |
| Standby power | mA | 5 | 6.5 | 10 |
| Operating temperature | TA | -40℃ | 85℃ | 105℃ |
The module fully complies with the WPC V1.2 QI protocol standard, making it widely compatible with various standard wireless charging receiver devices.
Yes, it supports the simultaneous wireless charging of up to 3 separate devices, specifically designed to power a mobile phone, earphones, and a smartwatch at the same time.
It supports multiple wireless transmission applications ranging from 5W up to 15W, providing adjustable power options based on your device requirements.
Absolutely. The system features a built-in 64KB FLASH memory, which natively supports online firmware and software upgrades via a C-port interface.
The system features FOD (Foreign Object Detection), NTC temperature protection, an integrated multi-channel ADC, and reliable protection systems against over-voltage, over-temperature, and output over-current issues.
The typical operating voltage is 5V (ranging from a minimum of 0.3V to a maximum of 5.8V). The safe operating temperature range spans from -40℃ to 105℃, with a typical performance profile centered at 85℃.
